| Model | Capacity (T) | Standard Lift (m) | Running Test (T) | Effort required to lift max load (N) | No.of falls of load chain | Load chain diameter(mm) | Dimension(mm) | Net Weight (kg) | Packing (LxWxH)(cm) | |||||
| A | B | C | D | L | H | |||||||||
| VJ-0.5T | 0.5 | 1.5 | 0.75 | 140 | 1 | 5 | 102 | 80 | 95 | - | - | - | 3.5 | 33.5x12.5x9 |
| VJ-0.75T | 0.75 | 1.5 | 1.125 | 140 | 1 | 6 | 148 | 88 | 135 | 32 | 290 | 320 | 7 | 37x14x17 |
| VJ-1T | 1 | 1.5 | 1.5 | 140 | 1 | 6 | 148 | 88 | 135 | 32 | 290 | 320 | 7.5 | 37x14x17 |
| VJ-1.5T | 1.5 | 1.5 | 2.25 | 240 | 1 | 8 | 176 | 102 | 155 | 36 | 415 | 380 | 11 | 52x14x18 |
| VJ-2T | 2 | 1.5 | 3 | 240 | 1 | 8 | 176 | 102 | 155 | 36 | 415 | 380 | 11.5 | 52x14x18 |
| VJ-3T | 3 | 1.5 | 4.5 | 320 | 1 | 10 | 195 | 109 | 211 | 46 | 415 | 480 | 19 | 55x16x21 |
| VJ-6T | 6 | 1.5 | 7.5 | 340 | 2 | 10 | 195 | 109 | 254 | 46 | 415 | 600 | 32 | 55x16x21 |
| VJ-9T | 9 | 1.5 | 11.25 | 360 | 3 | 10 | 195 | 109 | 319 | 57 | 415 | 700 | 47 | 62x48.5x26 |
