| Hydraulic Bottle Jacks Parameter | ||||||
| Model No | Load Capacity (Tons) | Minimum Height (In.) | Piston Lift (In.) | Head Screw (In.) | Maximum Height (In.) | Weight (Ibs) |
| QYL - 2T | 2 | 5 - 5 / 7 | 3 - 1 / 7 | 2 | 10 - 5 / 6 | 4.85 |
| QYL - 3T | 3 | 6 - 4 / 7 | 4 | 2 - 1 / 3 | 12 - 7 / 8 | 6.68 |
| QYL - 5T | 5 | 7 - 1 / 8 | 4 - 1/ 3 | 2 - 1 / 3 | 13 - 5 / 6 | 8.71 |
| QYL - 8T | 8 | 7 - 1 / 2 | 4 - 5 / 7 | 2 - 1 / 3 | 14 - 3 / 5 | 10.65 |
| QYL - 10T | 10 | 7 - 5 / 6 | 5 | 2 - 1 / 3 | 15 - 1 / 8 | 11.95 |
| QYL - 12T | 12 | 8 | 5 | 2 - 1 / 3 | 15 - 1 / 4 | 13.6 |
| QYL - 16T | 16 | 8 - 4/7 | 5 - 1 / 3 | 2 - 1 / 3 | 16 - 1 / 4 | 16.2 |
| QYL - 20T | 20 | 9 | 5 - 5 / 7 | 2 - 1 / 3 | 17 | 19.95 |
| QYL - 25T | 25 | 9 - 3 / 5 | 5 - 5 / 7 | 2 - 1 / 3 | 17 - 2 / 3 | 24 |
| QYL - 32T | 32 | 10 - 1 / 4 | 6 | 2 - 1 / 3 | 18 - 1 / 2 | 44.1 |
| QYL - 50T | 50 | 11 - 4 / 5 | 6 | - | 18 - 8 / 9 | 66.14 |
| QYL - 50T | 50 | 11 - 4 / 5 | 6 | 2 - 1 / 3 | 21 - 2 / 9 | 71.87 |
